Atlas shank tails

Product Model：

Product Size：

Packaging Size：

Packaging Method：

Product Features

The chisel adapter is mainly used in mining operations, and high-quality alloy steel is selected as the raw material, which is treated with integral carburizing. Special CNC machine tool processing equipment and processing process are used to ensure the processing quality of tail details, internal water holes and side water holes. The chisel head is uniformly heat-treated, and the precision instrument is used to scientifically straighten it to ensure the straightness and irritability of the shill head.

The function of the shank adapter is to directly absorb the impact energy and torque of the rock drill.

The size and hardness of the shank have a great impact on the drilling speed, the life of the rock drill and the chisel. Therefore, the length of the drill head should be appropriate, the end face should be smooth and clean, the section should be perpendicular to the axis, and be consistent with the rock drill sleeve (the gap should not be greater than 0.5mm). The hardness of the kit should be appropriate, the life of the soft kit is short, the piston is easy to be injured if it is too hard, the hardness of the kit should be slightly lower than the hardness of the piston, and the quenching hardness HRC=38~45 is appropriate.

钎尾 Shank adapter
阿特拉斯 Atlas Copco	配套凿岩机型 Rock drill	螺纹 Thread	长度 Length (mm)	重量 Weight (kg)	内孔直径 Flushing (mm)	P/N
	Atlas Copco COP 1038HL	R32 T38	575 575	4.9 5.2	- - -	41038HL-38R32-0575-23 41038HL-38T38-0575-23
	Atlas Copco COP 1038HL	T45	575	6.1	-	41038HL-45T45-0575-23
	Atlas Copco COP 1238	R32 T38 R38 T38	500 500 485 485	4.0 4.4 4.2 4.2	- - - -	41238-38R32-0500-23 41238-38T38-0500-23 41238-38R38-0485-23 41238-38T38-0485-23
	Atlas Copco COP 1238	T45	500	5.0	-	42138-45T45-0500-23
	Atlas Copco COP 1238	R32 R38 T38	575 575 575	4.9 5.0 5.2	- - -	41238-38R32-0575-23 41238-38R32-0575-23 41238-38R32-0575-23
	Atlas Copco COP 1238	T38 T45	575 575	5.7 6.1	- -	41238-45T38-0575-23 41238-45T45-0575-23
	Atlas Copco COP 1432, COP 1532, COP 1440, COP 1838 HD, COP 1838 ME	R32 R38 T38	435 435 435	3.9 4.2 4.2	- - -	41432-38R32-0435-23 41432-38R38-0435-23 41432-38T38-0435-23
	Atlas Copco COP 1432, COP 1532, COP 1440, COP 1838 HD, COP 1838 ME	R32 T38	525 525	408 5.0	- -	41432-38R32-0525-23 41432-38T38-0525-23
	Atlas Copco COP 1432, COP 1532	R32 R38	341 341	4.7 5.2	- -	41432-55R32-0341-23 41432-55R38-0341-23
	Atlas Copco COP 1550, COP 1838ME/HE	T38 T45 T51	525 525 525	6.2 6.4 6.8	- - -	41550-52T38-0525-23 41550-52T45-0525-23 41550-52T51-0525-23

			<th colspan="7" style="border:1px solid #ccc;padding:15px 0px;" "=""> 钎尾 Shank adapter
阿特拉斯 Atlas Copco	配套凿岩机型 Rock drill	螺纹 Thread	长度 Length (mm)	重量 Weight (kg)	内孔直径 Flushing (mm)	P/N
	Atlas Copco BBC 43, BBC 44, BBC 45, BBC 100	R32	380	2.2	10	4BBC43-32R32-10380-23
	Atlas Copco BBC 51, BBC 52, BBC 54, BBC 120	R32 T38	538	5.6	14	4BBE57-44T38-14538-23
	Atlas Copco BBE 57	T38	538	5.6	14	4BBE57-44T38-14538-23
	Atlas Copco COP 125, COP 130, COP 131	T38	380	3.3	14	4215-39T38-14380-23
	Atlas Copco COP 1032HD	R32	340	3.7	-	41032HD-45R32-0340-23
	Atlas Copco COP 1032HD	R38	340	4.4	-	41032HD-55R32-0340-23
	Atlas Copco COP 1032	R32 R35 R38 T38	550 550 550 550	5.3 5.6 5.7 5.7	- - - -	41032-45R32-0550-23 41032-45R35-0550-23 41032-45R38-0550-23 41032-45T38-0550-23
	Atlas Copco COP 1036 COP 1038HB	R32 T38	500 500	4.3 4.7	- -	41036-38R32-0500-23 41036-38T38-0500-23
	Atlas Copco COP 1036 COP 1038HB	T45	500	5.3	-	41036-45T45-0500-23
	Atlas Copco COP 1038HD COP 1238	R32 R38 T38	485 485 485	4.3 4.5 4.5	- - -	41238-38R32-0485-23 41238-38R38-0485-23 41238-38T38-0485-23
