Other models of shank adapters

Product Model：

Product Size：

Packaging Size：

Packaging Method：

Product Features

The chisel adapter is mainly used in mining operations, and high-quality alloy steel is selected as the raw material, which is treated with integral carburizing. Special CNC machine tool processing equipment and processing process are used to ensure the processing quality of tail details, internal water holes and side water holes. The chisel head is uniformly heat-treated, and the precision instrument is used to scientifically straighten it to ensure the straightness and irritability of the shill head.

The function of the shank adapter is to directly absorb the impact energy and torque of the rock drill.

The size and hardness of the shank have a great impact on the drilling speed, the life of the rock drill and the chisel. Therefore, the length of the drill head should be appropriate, the end face should be smooth and clean, the section should be perpendicular to the axis, and be consistent with the rock drill sleeve (the gap should not be greater than 0.5mm). The hardness of the kit should be appropriate, the life of the soft kit is short, the piston is easy to be injured if it is too hard, the hardness of the kit should be slightly lower than the hardness of the piston, and the quenching hardness HRC=38~45 is appropriate.

钎尾 Shank adapter
山特维克（汤姆洛克）, 其它Sandvik（Tamrock）, Others	配套凿岩机型 Rock drill	螺纹 Thread	长度 Length (mm)	重量 Weight (kg)	内孔直径 Flushing (mm)	P/N
	Tamrock HL 1500-60, HL 1500T-60	T51 T60	760 760	16.1 16.1	- -	4HL1500-60T51-0760-23 4HL1500-60T60-0760-23
	Tamrock HL 1500-T80	T60	760	22.9	-	4HL1500-80T60-0760-23
	Tamrock HL 1500-S80	ST58 ST68	635 635	18.8 18.9	- -	4HL1500-80ST58-0635-23 4HL1500-80ST68-0635-23
	Tamrock HL 1500-SPE90	ST58 ST68	635 635	21.8 21.9	- -	4HL1500-90ST58-0635-23 4HL1500-90ST68-0635-23
		HL64	1180	35.6	-	40THER-70HL64-1180-23
		R32	410	3.1	-	40THER-35R32-410-23
