The chisel adapter is mainly used in mining operations, and high-quality alloy steel is selected as the raw material, which is treated with integral carburizing. Special CNC machine tool processing equipment and processing process are used to ensure the processing quality of tail details, internal water holes and side water holes. The chisel head is uniformly heat-treated, and the precision instrument is used to scientifically straighten it to ensure the straightness and irritability of the shill head.

The function of the shank adapter is to directly absorb the impact energy and torque of the rock drill.

The size and hardness of the shank have a great impact on the drilling speed, the life of the rock drill and the chisel. Therefore, the length of the drill head should be appropriate, the end face should be smooth and clean, the section should be perpendicular to the axis, and be consistent with the rock drill sleeve (the gap should not be greater than 0.5mm). The hardness of the kit should be appropriate, the life of the soft kit is short, the piston is easy to be injured if it is too hard, the hardness of the kit should be slightly lower than the hardness of the piston, and the quenching hardness HRC=38~45 is appropriate.

钎尾 Shank adapter
山特维克（汤姆洛克）, 其它Sandvik（Tamrock）, Others	配套凿岩机型 Rock drill	螺纹 Thread	长度 Length (mm)	重量 Weight (kg)	内孔直径 Flushing (mm)	P/N
	Tamrock HL 1500-60, HL 1500T-60	T51 T60	760 760	16.1 16.1	- -	4HL1500-60T51-0760-23 4HL1500-60T60-0760-23
	Tamrock HL 1500-T80	T60	760	22.9	-	4HL1500-80T60-0760-23
	Tamrock HL 1500-S80	ST58 ST68	635 635	18.8 18.9	- -	4HL1500-80ST58-0635-23 4HL1500-80ST68-0635-23
	Tamrock HL 1500-SPE90	ST58 ST68	635 635	21.8 21.9	- -	4HL1500-90ST58-0635-23 4HL1500-90ST68-0635-23
		HL64	1180	35.6	-	40THER-70HL64-1180-23
		R32	410	3.1	-	40THER-35R32-410-23

钎尾 Shank adapter
山特维克（汤姆洛克）, 其它Sandvik（Tamrock）, Others	配套凿岩机型 Rock drill	螺纹 Thread	长度 Length (mm)	重量 Weight (kg)	内孔直径 Flushing (mm)	P/N
	Tamrock HL 300	R32	400	2.8	-	4HL300-32R32-0400-23
	Tamrock HL 300S	R32	245	2.8	-	4HL300S-45R32-0245-23
	Tamrock HLX 3	R32	324	3.8	-	4HLX3-45R32-0324-23 4HL1500-80ST68-0635-23
	Tamrock HLX 3F	R32	205	2.6	-	4HLX3F-45R32-0205-23
	Tamrock L400, L410, L500, L510, L550	R32	380	2.3	10	4L400-32R32-0380-23
	Tamrock HL 438, HL 538, HLR 438L, HLR 438T	R32 T38	380 400	3.2 3.6	12.7 12.7	4HL438-38R32-13380-23 4HL438-38T38-13400-23
	Tamrock HL 438LS, HL 438TS, HL 538, HL 538L, L 550S	R32 R38 T38 T38	450 450 455 545	4.1 4.3 4.3 4.8	- - - -	4HL538-38R32-0450-23 4HL538-38R38-0450-23 4HL538-38T38-0455-23 4HL538-38T38-0545-23
	Tamrock HL500-38 HL510-38	R32 T38	550 550	4.3 4.6	- -	4HL500-38R32-0550-23 4HL510-38T38-0550-23
	Tamrock HL500-45 HL510-45	R32 T38 T45	550 550 550	5.6 5.6 6.1	- - -	4HL500-38T38-0550-23 4HL500-45T38-0550-23 4HL500-45T45-0550-23

钎尾 Shank adapter
山特维克（汤姆洛克）, 其它Sandvik（Tamrock）, Others	配套凿岩机型 Rock drill	螺纹 Thread	长度 Length (mm)	重量 Weight (kg)	内孔直径 Flushing (mm)	P/N
	Tamrock HL 500S-38, HL 510S-38, HL 510B, HL 510HL	R32 R38 T38 R38 T38	460 460 460 500 500	3.9 4.1 4.1 4.3 4.3	- - - - -	4HL510B-38R32-0460-23 4HL510B-38R38-0460-23 4HL510B-38T38-0460-23 4HL510B-38R38-0500-23 4HL510B-38T38-0500-23
	Tamrock HL 500F, HL 510F	R32	350	3.6	-	4HL500F-45R32-0530-23
	Tamrock HL 550 SUPER, HL 560 SUPER, HL 510S-45	R32 T38 T45	500 500 500	5.5 5.5 5.6	- - -	4HL550-45R38-0500-23 4HL550-45T38-0500-23 4HL550-45T45-0500-23
	Tamrock HLX 5, HLX 5T	R32 R38 T38 R32 T38 T45	500 500 500 575 575 575	5.4 5.5 5.5 6.4 6.5 6.6	- - - - - -	4HLX5-45R32-0500-23 4HLX5-45R38-0500-23 4HLX5-45T38-0500-23 4HLX5-45R32-0575-23 4HLX5-45T38-0575-23 4HLX5-45T45-0575-23
	Tamrock HLX5 PE-45	R32 T38	575 575	6.3 6.4	- -	4HLX5PE-45R32-0575-23 4HLX5PE-45T48-0575-23
	Tamrock HL 600S-45, HL 600S-45	T38 T45 R32 T38 T45	600 600 525 525 525	6.7 6.7 5.9 6.0 6.1	- - - - -	4HL600-45T38-0600-23 4HL600-45T45-0600-23 4HL600-45R32-0525-23 4HL600-45T38-0525-23 4HL600-45T45-0525-23
	Tamrock HL 600-52, HL 600S-52	T45 T51	650 650	8.0 8.0	- -	4HL600-52T45-0650-23 4HL600-52T51-0650-23
	Tamrock HL 645, HL 645S	T38 T45	600 600	6.6 6.8	- -	4HL645-45T38-0600-23 4HL645-45T45-0600-23
	Tamrock HL 650-45, HL700-45, HL 700T-45, HL 710-45, HL 800T-45	T38 T45	600 600	7.3 7.8	- -	4HL650-45T38-0600-23 4HL650-45T45-0600-23

钎尾 Shank adapter
山特维克（汤姆洛克）, 其它Sandvik（Tamrock）, Others	配套凿岩机型 Rock drill	螺纹 Thread	长度 Length (mm)	重量 Weight (kg)	内孔直径 Flushing (mm)	P/N
	Tamrock HL 650-52, HL 700-52, HL 710-52, HL 800T-52	T38 T45 T51	600 600 600	8.3 8.8 8.8	- - -	4HL650-52T38-0600-23 4HL650-52T45-0600-23 4HL650-52T51-0600-23
	Tamrock HL 850 HL 850S	T45 T51	670 670	9.8 10.1	- -	4HL850-52T45-0670-23
	Tamrock HL 1000-52, HL 1000S-52	T45 T51 T45 T51	670 670 590 590	10.3 11.0 8.7 8.7	- - - -	4HL1000-52T45-0670-23 4HL1000-52T51-0670-23 4HL1000-52T45-0590-23 4HL1000-52T51-0590-23
	Tamrock HL 1000-60	T51 T60	670 670	13.3 13.4	- -	4HL1000-60T51-0670-23 4HL1000-60T60-0670-23
	Tamrock HL 1000-80	T60	670	20.9	-	4HL1000-80T60-0670-23
	Tamrock HL 1000S-80	ST58 ST68	635 640	18.2 19.1	- -	4HL1000S-80ST58-0635-23 4HL1000S-80ST68-0640-23
	Tamrock HL 1000PE-2	T51	840	14.2	-	4HL1000PE-52T51-0840-23
	Tamrock HL 1000 PE-65, HL 1500 PE-65, HL 1560 T-65	T51 T60	760 760	16.8 16.9	- -	4HL1000PE-65T51-0760-23 4HL1000PE-65T60-0760-23
	Tamrock HL 1500-52, HL1500T-52	T51	710	11.9	-	4HL1500-52T51-0710-23
