Ingersoll Rand

Product Model：

Product Size：

Packaging Size：

Packaging Method：

Product Features

The chisel adapter is mainly used in mining operations, and high-quality alloy steel is selected as the raw material, which is treated with integral carburizing. Special CNC machine tool processing equipment and processing process are used to ensure the processing quality of tail details, internal water holes and side water holes. The chisel head is uniformly heat-treated, and the precision instrument is used to scientifically straighten it to ensure the straightness and irritability of the shill head.

The function of the shank adapter is to directly absorb the impact energy and torque of the rock drill.

The size and hardness of the shank have a great impact on the drilling speed, the life of the rock drill and the chisel. Therefore, the length of the drill head should be appropriate, the end face should be smooth and clean, the section should be perpendicular to the axis, and be consistent with the rock drill sleeve (the gap should not be greater than 0.5mm). The hardness of the kit should be appropriate, the life of the soft kit is short, the piston is easy to be injured if it is too hard, the hardness of the kit should be slightly lower than the hardness of the piston, and the quenching hardness HRC=38~45 is appropriate.

钎尾 Shank adapter
古河/戈登丹佛/英格索兰/蒙塔贝特 Furukawa,Gardenr-Denver,lngersoll-Rand and Montabert	配套凿岩机型 Rock drill	螺纹 Thread	长度 Length (mm)	重量 Weight (kg)	内孔直径 Flushing (mm)	P/N
	Furukawa HD 609	T38 T38 T45	620 690 620	6.2 6.5 6.9	- - -	4BBC43-32R32-10380-23
	Furukawa HD 612	T45	710	9.2	-	4HD612-51T45-0710-23
	Furukawa HD 712	T45	788	11.2	-	4HD712-51T45-0788-23
	Gardenr-Denver PR 123	R32 R38 T38 T45	380 380 380 380	3.6 3.9 3.9 4.2	14.3 14.3 14.3 14.3	4PR123-44R32-14380-23 4PR123-44R38-14380-23 4PR123-44T38-14380-23 4PR123-44T45-14380-23
	lngersoll-Rand URD475, URD550, VL120, EVL 130, VL140, F16	R32 R38 T38 T38	330 350 380 446	3.6 3.8 4.0 4.3	14 14 14 14	4VL120-44R32-14330-23 4VL120-44R38-14350-23 4VL120-44T38-14380-23 4VL120-44T38-14446-23
	lngersoll-Rand YH 65, YH 80	T38 T45	500 500	5.8 6.1	19 19	4YH65-45T38-19500-23 4YH65-45T45-19500-23
	lngersoll-Rand YH 65 RP, YH 70 RP, YH 80 RP	T45	700	8	19	4YH65RP-45T45-19700-23
	Montabert HC 40	R32 R38 T38	447 447 447	3.9 4.1 4.1	- - -	4HC40-38R32-0447-23 4HC40-38R38-0447-23 4HC40-38T38-0447-23
	Montabert HC 40	R32	270	4.1	-	4HC40-52R32-0270-23
	Montabert HC 40	R38	320	4.4	-	4HC40-55R38-0320-23
